arcelik BEKO G91632NE User Manual

SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
52
Sensitivity: Public
12.1.2. Teka handle group
Service numbers used:
1546 Fridge handles
1547 Freezer handles
 Arçelik handle group is as illustrated in Picture 1.
 Separate the fridge handle plastic parts with a knife, etc. as shown in Picture 2 and
remove by pulling downwards.
 Separate the freezer handle plastic parts with a knife, etc. as shown in Picture 2 and
remove by pulling upwards.
 Remove 10 pcs of 3x10 PT screws used in the fridge and freezer handles by attaching
the torque bit to the chargeable gun, as shown in Picture 4.
 Remove the fridge handle tabs by pushing them upwards from their slots in the door
plate.

Remove the freezer handle tabs by pushing them downwards from their slots in
the door plate.
