SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
82
Sensitivity: Public
Used service number: 995
It is assembled on the return pipe.
12.32. Service pipe
Service numbers used:
125 service pipe plastered
125A service pipe L=60mm
12.33. Compressor
dryer
Bitumin
ous
return
pipe
heater
pipe
L=60mm
service
pipe
service
pipe
copper
adaptor
pipe
Coil
condenser
pipe
