6.4. Connection of the inline (external) filter
External filter group which is given in the product is attached to an area near the
water mains as shown in the picture.
It is important that the filter stands upright as illustrated.
By attaching one end of the pipe into the water valve and the other end to the mains
inlet, water can be supplied directly from the mains.
WARNING: Water filter must be held upright as shown in the
figure. It is important to properly attach the filter to water inlet and
water outlet.
After attaching the filter, do not use the first 3-4 glasses of water.
WARNING: Never mount the filter onto the refrigerator. Otherwise,
refrigerant pipes may be punctured!
UNION
FITTING TO
BE
CONNECTED
TO THE TAP
