Aerosol Photometer
Aerosol Photometer - 2i 22
If the unit is used in a manner not specified within the
user’s manual, the protection offered by the equipment
may be impaired.
Before you begin
You will need the following items to set up the Aerosol
Photometer Model 2i
Electrical outlet (110 VAC or 220 VAC)
2i Scanning Probe or PVC Sampling Tube
1°C to 45°C ambient temperature
Less than 95% RH, non-condensing.
i
Note
High ambient temperatures may create instability in the
readings.
Connecting Electrical Power
Voltage and current requirements for the Aerosol
Photometer Model 2i are:
100 to 240 VAC, 2 amps
The Aerosol Photometer automatically adjusts to
operate at the correct AC voltage for the destination
country (given this voltage is within the specifications
described in “APPENDIX D Specifications page 70).
This voltage is noted on a label attached to the back
panel of the instrument. The power cord contains a
plug which is specifically adapted to the destination
country.
You are responsible for plugging the power cord into
a matching receptacle. To connect the Aerosol
Photometer to electrical power, do the following:
1. Check to make sure the Aerosol Photometer is
turned off. (Refer to Figure 2: Rear Panel Overview,
for the location of the power switch.)
