Aerosol Photometer
Aerosol Photometer - 2i 30
Function Keys
The function keys on the iProbe are identical to those
of the 2i front panel. The iProbe, however, does not
have a power button.
Power Button
To turn the instrument ON and OFF.
Arrow Pad Buttons
To navigate the menus, change
values and validate choices. The
center button is the enter key.
Play / Pause Button
To start the summary or monitoring
reporting functions as well as pause
them.
Stop Button
To stop the summary or monitoring
reporting functions.
Mute Button
To mute the audible and vibratory
alarms.
Keyboard Button
To call the keyboard to the screen
for entering a scanning location.
Sampling Ports
The sampling ports connect the instrument to either
the scanning probe or 12 feet of clear tubing. They
are quick-connect type connectors and are
removable.
Each port contains a lint trap that should be cleaned
periodically to prevent clogging (see “Maintaining the
Photometer” page 61 for the procedure).
