Aerosol Photometer
Aerosol Photometer - 2i 27
Rear Panel General Overview
Figure 2: Rear Panel Overview
Description Function
Printer Port Connection port for the optional thermal printer.
USB Port Connection port to interface with a computer or data
acquisition system.
Power Entry
Module
Connects the instrument to the wall outlet. It also contains the
fuses.
Instrument
Identification
Provides the operator with useful information regarding the 2i,
such as serial number and power ratings.
Cooling Fan Provides temperature management inside the instrument
enclosure.
USB Port
Printer Port
Power
Entry
Module
Cooling Fan
Instrument
Identification
