ATI Technologies 2i User Manual

Aerosol Photometer
Aerosol Photometer - 2i 40
Icons
The following table describes the different icons
displayed on the 2i user interface.
Table 4: Icons Description
Icon Displayed when …
The optional thermal printer is plug
into the instrument.
A computer is interfaced with the USB
port.
The Upstream Aerosol Noise
Suppression (UANS) is selected.
The Downstream Aerosol Noise
Suppression (DANS) is selected.
The Continuous reporting function is
selected.
The Monitoring reporting function is
selected.
The Summary reporting function is
selected.
The iProbe is connected.
The mute function is enabled.
The Audible alarm is enabled.
The Audible alarm is disabled.
The Vibratory alarm is enabled.
The Vibratory alarm is disabled.
The Visual alarm is enabled.
The Visual alarm is disabled.
The instrument is sending data to the
USB and Printer port.
The data transmission to the USB and
Printer port is paused when in
Summary reporting mode.
Toggle the running mode and the main
menu on the iProbe.
