ATI Technologies 2i User Manual

Aerosol Photometer
Aerosol Photometer - 2i 37
Figure 6: Sample Summary Mode Reporting Ticket
Monitoring
The monitoring mode reporting function is similar to
the summary mode reporting function. It differs in the
content and format of the data set and footer. In this
mode the data is only available on the USB port. The
data set is described in the following table.
i
Note
In Monitoring mode, the operator cannot pause the
acquisition of data set.
Table 3: Monitoring Reporting Mode Ticket
Header
Photometer Model
Unit Serial #
Calibration Due Date
Date
Field Separator
Location or Filter ID
Setup
Reference Used
Actual Concentration
Upstream Value
ATI Photometer 2i
Serial #: 123456
Cal Due: 1 May 2013
Date: 1 May 2012
-------------------
ID: FILTER 123
Setup: Internal Ref
Reagent: PAO
Actual Con.: -
Upstream Val: 100
Start Time: 12:00
-------------------
Leakage Alarm: 0.010%
Alarm Exceeded: No
Max Pen.: 0.0004%
-------------------
Leakage Alarm: 0.010%
Alarm Exceeded: Yes
Max Pen.: 0.0403%
-------------------
Leakage Alarm: 0.010%
Alarm Exceeded: Yes
Max Pen.: 0.0706%
-------------------
End Time: 12:19
Scan Time: 3 Min 24 sec
Operator:
