Aerosol Photometer

Aerosol Photometer - 2i 48

Alarm Set Point

Changing the alarm set point

Figure 14: Setting the Alarm Set Point Screenshot

Table 7: Alarm Set Point Options List

Parameter Function Icon Limits

Alarm Set

Point

Change the alarm

threshold for %

leakage.

N/A

0.001 to 100

16 Feb 2012 09:59

Reagent

Alarm Set Point

PAO

0.001

Alarm Set Point

Alarms

0.001

Cancel Default

Save

Alarm Set Point

Default

0.001

PAO
