Aerosol Photometer
Aerosol Photometer - 2i 38
% Leakage Alarm
Start Time
Field Separator
Data Set
Time
Leakage
Alarm
Alarm
Exceeded
% Leakage
Value
Footer
Field Separator
End Time
Field Separator
Figure 7: Sample Monitoring Mode Data Output
Continuous
The continuous reporting mode will output one %
leakage reading approximately every second to the
USB port of the instrument. The data consists of the
penetration value followed by a comma.
i
Note
The Continuous reporting mode provides a data output
identical to the legacy equipment TDA-2G and TDA-2H.
To use an existing data acquisition system with the 2i
adjust the port settings as described in “Connecting the
Interface Ports” page 24.
ATI Photometer 2i
Serial #: 123456
Cal Due: 26 Feb 2013
Date: 29 Feb 2012
-------------------
ID:
Setup: Internal Ref
Reagent: PAO
Actual Con.: -
Upstream Val: 100
Start Time: 09:19:00
-------------------
Timestamp, Leakage Alarm, Alarm Exceeded, Maximum Penetration
4, 0.010%, No,0.0046%
8, 0.010%, No,0.0049%
12, 0.010%, No,0.0053%
16, 0.010%, No,0.0052%
20, 0.010%, No,0.0054%
24, 0.010%, No,0.0053%
28, 0.010%, No,0.0054%
32, 0.010%, No,0.0054%
36, 0.010%, No,0.0053%
40, 0.010%, No,0.0053%
44, 0.010%, No,0.0051%
48, 0.010%, No,0.0052%
-------------------
End Time: 09:19:48
-------------------
