Consistency Check
of Configuration Data
Commissioning Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-COMMISS/EGB Rev.F, 2014-04-01,
Autronica Fire and Security AS
Page 10
4.3 Importing Loop Data from the AS-2000 Tool
The AutroSafe Configuration Tool features an Import command
allowing you to import loop data directly from the AS-2000 Loop
Diagnostic tool. In this way, it is possible to ensure that the point types
and sequence indexes in the configuration will be identical to the real
loop. Tag Names and optional Detection Zones (DZs) will be assigned
to the points during import.
For further information, refer to the Help System for AutroSafe
Configuration Tool and the User Guide for the AS-2000 Loop
Diagnostic Tool.
4.4 Consistency Check Using the
AS-2000 / Config Mismatch Tool
4.5 Generating Configuration Files
System configuration is done from a computer by the means of the
AutroSafe Configuration Tool. This tool allows you to generate
configuration files, which then can be uploaded to target after the
system has been verified.
The AutroSafe Configuration Tool allows you to do a
consistency check of configuration data by means of a menu
called AS-2000 / Config Mismatch Tool (in the Tool menu).
This feature allows you to easily compare the actual
configuration data downloaded from a detection loop and
imported to the AutroSafe Configuration Tool (using
the AS-2000) with the configuration data you have entered in
the AutroSafe Configuration Tool.
