Autronica AUTROSAFE 4 User Manual

Power Commissioning
Commissioning Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-COMMISS/EGB Rev.F, 2014-04-01,
Autronica Fire and Security AS
Page 14
5.1.4 Power Board Configuration Switches
The settings of the dipswitches are read during startup. If the switches
are changed for any reason, the changes will not take affect until the
Power Board is restarted (pressing the reset button S1 on the Power
Board).
Dipswitch table – S5
S5.1
S5.2
Function
OFF
OFF
AutroFieldBus earth fault OFF
ON
ON
AutroFieldBus earth fault ON
Dipswitch table – S6
Switch
Name
Comment
S6-1 Earth Fault
ON: Earth fault monitoring
activated
OFF: Earth fault monitoring
deactivated
S6-2 NA
Must always be set to OFF
(default).
S6-3 AutroFieldBus
ON: AutroFieldBus connected
OFF: AutroFieldBus not
connected
S6-4
NA
-
S6-5
Battery
ON: Battery connected
OFF: Battery not connected
S6-6
Power Unit Type
ON: BPS-405
OFF: BPS-410
