11.98
Installing alternator
•
Install alternator.
Adjusting procedure for Poly-V belt:
Installation procedure for Poly-V belt:
•
Place Poly-V belt in position, tension, turn the
engine over once and relieve belt tension.
Poly-V belt tensioning procedure:
•
Screw up hex nut (1) at adjusting screw (2) lightly
by hand, (using no tools).
•
Tighten adjusting screw (2) with a torque wrench,
fully tighten retaining nut (3), slacken adjusting
screw and tighten screws fully.
X Tightening torque:
Pre-tension Poly-V belt
with adjusting screw....................................... 8 Nm
Alternatorto alternator support cover............ 20 Nm
•
Install front cover.
1
2
3
RS110480
RS110490
