23.17
Removing and installing detent lever
•
Remove washer (1).
•
Remove keeper (2).
•
Remove stop lever (3) with spring and washer.
Removing and installing shift pawls
•
Remove keeper (4).
•
Remove pawl (5) and spring from pawl holder.
Removing and installing torsion spring
•
Remove retaining ring (6).
•
Remove torsion spring (7) with washers.
Removing and installing selector shaft
seal
•
Remove bearing bushing (1) from sliding seat.
•
Force out shaft seal with drift, working from the
inside
•
Drive in the seal with drift, BMW No. 23 4 611.
•
Install bearing bushing.
1
4
3
5
6
7
RS230071
2
23 4 611
1
RS230100
