46.20
Removing and installing side
stand
•
Disconnect tension springs.
•
Remove si
de stand.
•
Disconnect
plug (1) fr
om side stand
switch and
remove switch.
•
Install i
n the reverse ord
er of work.
e
Caution:
Note: correct c
able run (arrow.
Lubricant:
...........
.......
e.g. Sta
burag
s NBU 3
0 PT
M
X
Tighteni
ng torque:
Side stand to pivot
mount
(clean thre
ad + Loctite 2701
)
..
.........
........
.....
42 Nm
1
RS610050
GS460220
362
