BMW R 1100 RS User Manual

00.25
Renewing fuel filter
(Inspektion III)
•
Remove dualseat.
•
[RS/RT] Take off side sections of fairing.
•
[RS] Detach cockpit inner panel (1) at fuel tank.
•
[GS] Remove right side fairing.
•
[R] Remove fuel tank cover.
•
[RT] Detach storage compartment
•
Unfasten fuel tank mount (2)
•
Seal off fuel feed and return line (3) with hose clip,
BMW No. 13 3 010, loosen and pull off.
•
Remove vent pipes (4).
•
Remove fuel pump connector (5).
•
Lift off fuel tank.
RS
1
5
3
4
2
13 3 010
RS160010

BMW R 1100 RS Specifications

General

Displacement	1085 cc
Transmission	5-speed
Final Drive	Shaft drive
Engine Type	Air/oil-cooled flat twin (boxer)
Power	66 kW (90 hp) at 7, 250 rpm
Torque	95 Nm at 5500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Fuel Capacity	22 liters
Seat Height	800 mm
Wheelbase	1471 mm
