Order No. 01 71 9 799 171 UX-VS-1, 7/95 Printed in Germany
Designation Data Measuring unit or
specification
Oilcapacities
Engine (incl. filter)
Engine (without filter renewal)
Gearbox
Rear wheel drive
3.75
5.50
fresh fill 1.0
change 0.8
fresh fill 0.25
change 0.23
litre
litre
[SI 11 048 90]
Brand-name HD oil for
petrol engines of API classi-
fication SE, SF, SG;
combination with CC or CD
specification
litre
litre
litre
litre
Valve clearance
measured cold, i.e. at max. 35 °C
E 0.15 / A 0.30 mm
Ignition
Static ignition
disconnect at
6° b TDC
Spark plugs
Electrode gap
limit of wear
Bosch FR5DTC
0.8
1.0
mm
mm
Engine idle speed 1000 +150 1/min
CO value (without catalytic converter) 1.5 ±0.5 Vol %
Cable adjustment
for increased cold starting speed (without cable junction)
(with cable junction)
throttle (without cable junction)
gas cable (one piece)
connecting cable
throttle (with cable junction)
gas cable (one piece)
junction cable
< 1
no backslash
ca. 0.5
no backslash
ca. 0.5
no backslash
mm play
mm play
mm play
Clutch cable adjustment
wire cable at handle bar lever
at lever
12.0
7.0
mm thread
mm play
Tyre pressure
depending on load and speed
front: 2.2 – 2.5
rear: 2.5 – 2.9
bar
bar
Tightening torques:
Oilfilter
Engine oil drain plug
Gearbox oil drain plug
Rear wheel drive oil drain plug
Locknut valve adjustment
Cylinder head cover
Generator to bracket
Tension multiple ripped belt (Poly-V)
Spark plugs
Fuel tank to rear frame
Fuel pump to tank
Adjustable handle bars
Quick release axle thread (axial)
Quick release axle clamp
Brake caliper
Bearing bolt swingarm to gearbox/rear axle
Idler bearing pin on swinging arm on gearbox/rear wheel drive
Locknut
Rear wheel retaining studs
Tube clips to air intake pipe
Screw connect. spring strut on control arm (RS with slide bearing)
Tighten cylinder head
– M 10 screw
11
32
23
23
8
8
20
8
20
22
6
20
30
22
front / rear 40
150 (Loctite 2701)
7 (Loctite 2701)
105 (Loctite 2701)
105
2
43
Thighten 20
180
40
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm (clean thread)
Nm (clean thread)
Nm (clean thread)
Nm
Nm
Nm (8.8 screw)
Nm
° Torsion angle
Nm
BMW AG Motorcycle Division
Service Data
R 1100 RT/R 1100 RS/R 1100 GS/R 1100 R/R 850 R
