BMW R 1100 RS User Manual

21.8
•
Detach lead to oil pressure switch.
•
Detach lead to side stand switch.
•
Detach lead for injector.
•
Detach lead for throttle angle sensor.
•
Locate the gearbox when removing and installing
with oiled guide pins, BMW No. 23 1 820.
•
Remove rear wheel, rear wheel drive unit and
swinging arm together with gearbox.
e Caution:
Hold gearbox at installation height until entire clutch
push rod is visible, or else this may be bent.
•
Install in the reverse order of work.
23 1 820
23 1 820
RS230011

BMW R 1100 RS Specifications

General

Displacement	1085 cc
Transmission	5-speed
Final Drive	Shaft drive
Engine Type	Air/oil-cooled flat twin (boxer)
Power	66 kW (90 hp) at 7, 250 rpm
Torque	95 Nm at 5500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Fuel Capacity	22 liters
Seat Height	800 mm
Wheelbase	1471 mm
