BMW R 1100 RS User Manual

33.22
•
Apply a weight of approx. 85 kg to the motorcy-
cle and tighten the strut (5) previously
loosened.
X Tightening torque:
Reaction link to rear wheel drive................... 43 Nm
•
Tighten clamping strap (6) on gaiter.
•
If necessary, fill with oil.
Fill quantity:
Initial filling............................0.25 l (0.44 Imp. pints)
During oil changes .............0.23 l (0.405 Imp. pints)
Oil grade:
Brand-name hypoid gear oil, SAE 90, API class
GL 5
•
[ABS]/[RS/R/RT] Install the brake disc in the
previously marked position.
•
Install the rear wheel.
•
Install brake caliper.
e Caution:
Do not damage brake pads; do not tilt when
installing.
•
[GS/R/RT]/[ABS] Install the sensor.
•
[ABS] Check that sensor gap is correct.
ABS rear sensor gap: ....................0,45...0,55 mm
.............................................. (0.0177...0.02165 in)
•
[RS] Install the number plate holder.
•
[GS] Install the rear wheel cover.

BMW R 1100 RS Specifications

General

Displacement	1085 cc
Transmission	5-speed
Final Drive	Shaft drive
Engine Type	Air/oil-cooled flat twin (boxer)
Power	66 kW (90 hp) at 7, 250 rpm
Torque	95 Nm at 5500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Fuel Capacity	22 liters
Seat Height	800 mm
Wheelbase	1471 mm
