BMW R 1100 RS User Manual

36.9
•
Heat bearing seat.
•
First insert wide bearing using drift,
BMW No. 36 5 511, and handle,
BMW No. 00 5 500.
•
Clamp arbor, BMW No. 36 5 511, in vise and
place wheel on it with wide bearing (2) in contact
with arbor.
•
Install spacer tube (1).
•
Bearing seat temperature 80 °C.
•
Insert narrow bearing (3) with drift,
BMW No. 36 5 512, and handle,
BMW No.005500.
•
Install retaining ring and driver.
•
Drive in shaft sealing ring with drift,
BMW No.365500, and handle,
BMW No.005500.
j
80
RS360025
00 5 500
36 5 511
RS360026
00 5 500
36 5 511
1
2
3
00 5 512
RS360028
00 5 500
36 5 500
RS360027

BMW R 1100 RS Specifications

General

Displacement	1085 cc
Transmission	5-speed
Final Drive	Shaft drive
Engine Type	Air/oil-cooled flat twin (boxer)
Power	66 kW (90 hp) at 7, 250 rpm
Torque	95 Nm at 5500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Fuel Capacity	22 liters
Seat Height	800 mm
Wheelbase	1471 mm
