D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 39
Bosch Security Systems | 10/03 | 47775E
A# Area Type
Default: Regular
Selection:
Regular, Master, Associate, or Shared
Regular Arms or disarms as an independent area.
Master Does not allow arming for this area unless all associate areas with the same A# account number are
master exit delay arming or master armed. CHK AREA displays if the associate areas are not armed.
Exception: RPS allows master areas to be armed without all associate areas being in the armed
state.
A master area can be disarmed regardless of the armed state of the other areas in the account.
Multiple master areas can be programmed in a single account.
0101
0101
0101
Programming Tip:
CC# Scope affects master arming
Area:
A master area with a CC# Scope Area requires the associate areas
are independently armed, or master exit delay before the master area can arm.
Panel Wide/Account Wide:
Upon arming the master area, all associate areas
within the CC# Scope of the master area begins Master Exit Delay Arm. The
shared areas begin.
Using the arming sked (S## Function 1) requires that you first use an arming
sked to arm the associate areas before using an arming
sked to arm the master
area. In addition, arming master areas with RAM IV, Keyswitch, or Auto Close
parameters (see Open/Close Options) is allowed to occur before all associate
areas are armed.
Associate Allows arming and disarming regardless of the armed state of the other areas with the same A#
account number. This type of area is used with a master area and is associated by having the same
account number.
Command centers assigned to associate areas, when used in conjunction with
shared areas, should have the CC# Scope programmed to encompass the
shared area.
Shared Shared areas cannot be armed using a passcode, keyswitch, sub-control, sked, or by RAM. Doing so
produces a Watchdog Reset.
The scope of all associate areas must include the shared area(s) in order to view
faulted points.
