4.1.1 Point Responses
Applications for Point Responses 9, D,
and E:
Combine Point Responses 9, D, and E with
Perimeter point types to create more flexible
24-hour protection. Unlike 24-hour points, a
faulted Perimeter point with a Point
Response of D and E displays at the
command center when arming. Like a 24-
hour point, a point programmed this way can
generate alarms whether the area is armed
or disarmed.
Combining Point Response 9 with the Local
While Disarmed feature provides off-site
reporting when the area is armed, but only
local alarm annunciation when the area is
disarmed.
Combining Point Response 9 with the Local
While Armed feature provides off-site
reporting when the area is disarmed, but
only local alarm annunciation when the area
is armed.
Point Response E: Use this for Zonex/Asic
motion detectors. The control panel can
report troubles while Master Armed.
Point Response F: Does not sound at local
command centers but activates RlyResp
Type 1 and command center faults. To
annunciate the off-normal state at a
command center, program Disp as Dvc as
Yes and/or BuzzOn Fault as 1 or 2. This
point response does not generate alarms or
activate an alarm relay.
Point Response 8, 9, A, B, and C provide
supervisory (24-hour) reporting.
Characteristics of a Fire Point:
Reporting: When a group of events occur,
the control panel routes and prints out Fire
Reports first.
Visual Annunciation: Fire troubles continue
to scroll until the trouble is cleared. Once
acknowledged, FIRE TROUBLE scrolls to
let the end user know that a Fire point, or
group of Fire points, is still in trouble. Panel-
Wide Relays, Summary Fire, and
Summary Fire Tbl activate if a relay is
assigned when any Fire point goes into
alarm or is in trouble.
Audible Annunciation: A Fire point
activates the A# Fire Bell relay
programmed in Relay Parameters. The
amount of time and pattern of the relay
activation is programmed by area in Bell
Parameters, A# Fire Time, and A# Fire
Pat.
Supervisory: A Fire point can send a Fire
Supervisory Report and activate the
Summary Fire, Sup and Summary Fire
Tbl, Panel-Wide Relays with a P##
Response of 8-9-A-B-C.
Alarm Verification: A Fire point can delay
an alarm by the time programmed in A#
Verify Time in the Area Parameters.
Combined with A# Resettable, a Fire point
also resets the electrical circuit for the verify
time amount.
Reset Sensor: A fire device that requires
resetting can be manually reset using the
reset sensor relay for the area it is assigned
to.
Fire Walk: Use the Fire Walk function to
test Fire points in the system.
To provide an audible tone for a restored
Fire Supervisory point, use P## RlyResp
Type 1 and connect to a graphic
annunciator.
