D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 92
Bosch Security Systems | 10/03 | 47775E
P### Point Index
Default: See
Program Record Sheet
Selection: Blank (00) to 31
This entry selects one of the 31
P## Index
codes
that define the point’s characteristics and determines
how the control panel responds to various point
conditions.
Blank (00) disables the point.
Missing Point Reports occur if a point
address does not exist for a point assigned
a point index. Extra Point Events occur if
more than two devices have the same
address.
When a POPIT is missing, the control panel
generates the following responses based
on the point type:
• Fire points generate missing trouble
responses.
• Non-fire 24-hour points generate
missing alarm responses.
• Non-fire, non 24-hour points generate
missing alarm responses while armed,
and trouble responses while disarmed.
Exception: Non-fire, non-24-hour points
with a point response of 9 to D
generate a missing alarm response
while disarmed.
POPIT modules monitor their sensor loops
for three conditions: loop normal, loop
open, and loop shorted. They report these
three conditions to the control panel. The
control panel uses point programming to
interpret the sensor loop information
reported by the POPITs and to make the
appropriate system response.
P### Area Assign
Default: 1
Selection: 1 to 8
The areas are numbered 1 to 8. Select the area
number to which the point is assigned.
P### Debounce
Default: 2
Selection: 1 to 15
1 .300 seconds
2 .600 seconds
3 .900 seconds
4 1.2 seconds
5 1.5 seconds
6 1.8 seconds
7 2.1 seconds
8 2.4 seconds
9 2.7 seconds
10 3.0 seconds
11 3.3 seconds
12 3.6 seconds
13 3.9 seconds
14 4.2 seconds
15 4.5 seconds
The debounce count is the number of times the
control panel scans a point before initiating an
alarm. Scan cycles are 300 ms.
For appropriate settings consult the manufacturer’s
instructions for the device connected to this point.
0101
0101
0101
Bosch Security Systems recommends an
entry of two or higher. Interior Follower
points need a debounce of at least three.
Door points assigned to D9210B modules
need a debounce of at least four.
To Next Page
