4. Expansion options
The standard ControlSpace
®
AMS-8 includes:
•8linelevelanalogueaudioinputchannels(CS-TIC)
•8linelevelanalogueaudiooutputchannels(CS-TOC)
•8generalpurposecontrolcontactinputs
•1generalpurposecontrolcontactoutput
•1Ethernetcommunicationport
The ControlSpace
®
AMS-8 system can be expanded with additional user interfaces,
optional cards and communication interfaces.
Optional user interfaces:
CS-PP - ControlSpace
®
AMS-8 Paging Panel
With the ControlSpace
®
AMS-8 Paging Panel both pre-recorded and
realtime voice messages can be relayed to a selected group of zones.
CS-WC - ControlSpace
®
AMS-8 Wall Controller
With the ControlSpace
®
AMS-8 Wall Controller the channel can be selected and
the volume of the audio signal can be adjusted locally.
CS-LIM - ControlSpace
®
AMS-8 Local Input Module
The ControlSpace
®
AMS-8 Local Input Module allows a local source
(line or microphone) to be added to the system.
CS-RC - ControlSpace
®
AMS-8 Remote Control
The ControlSpace
®
AMS-8 Remote Control (infrared)
allows easy control of the Wall Controller up to 5 meters.
Optional Cards:
CS-TIC - ControlSpace
®
AMS-8 Twin Input Card
Up to four ControlSpace
®
AMS-8 Twin Input Cards can be added per frame to provide an additional 8 line
analogue audio input channels.
CS AMS-8 Audio link Card
The ControlSpace
®
AMS-8 Audio Link Card allows up to ten frames to be connected together.
Audio link cables are also required.
4. Optional system components
