Flush mount box
The flush mount box is suitable for in-wall mounting of the ControlSpace
®
AMS-8 wall
controller and ControlSpace AMS-8 local input module.
Dimensions (HxWxD): 7,1 x 10,6 x 5,2 cm
Surface mount box
The surface mount box is suitable for on-wall mounting of the ControlSpace
®
AMS-8
wall controller and ControlSpace AMS-8 local input module.
Dimensions (HxWxD): 8,0 x 11,4 x 4,6 cm
Dry lining box for plasterboard walls
Dry lining box for hollow or plasterboards walls for in-wall mounting of the
ControlSpace
®
AMS-8 wall controller and ControlSpace
®
AMS-8 local input module.
Dimensions (HxWxD): 6,6 x 12,4 x 5,2 cm
Paging panel
Use these dimensions to mount the paging
panel into a desk or other. Mount a separate
XLR-connector (female) next to the paging panel,
which needs to be connected to the microphone
connection inside the paging panel. In order to avoid
any short circuit, remove the power connection before
mounting the paging panel.
ANNEX B. User Interface mounting instructions
ANNEX B. User Interface mounting instructions
