76 Section 3: Wire Schematics and Pin-Outs
Model 490000 EFI Electrical Schematic
(Page 1 of 2)
J1-17
J1-09
J2-18
VBAT
VBAT
J2-15
IGN
GND
MPR
MPR
Main Power
Relay
Battery
12V
-+
GND
(POWER )
BLACK
20A Fuse
(Yellow)
15A Fuse
(Blue)
9
10 4
3
RED
RED
RED
ECM
Safety Circuit Input
Stand Alone System
J1-14
ORANGE/WHITE
J2-14
J2-17
J2-07
J2-10
J2-10
1
2
SENSOR INPUTS
MPR
C
D
A
B
RED
Manifold Air
Pressure and
Temperature
Sensor
Engine Head
Temperature
Sensor
Heated
Oxygen
Sensor
TAN
BROWN
GREY/BLACK
BROWN
WHITE/GREEN
EHT SENSOR SIGNAL
O
2 SENSOR SIGNAL
O
2 SENSOR HEATER
CONTROL
J2-08
3
TAN/BLACK
MAT SENSOR SIGNAL
J2-11
1
WHITE/RED
MAP SENSOR SIGNAL
J2-16
2
RED/WHITE
5 VOLT REFERENCE
J2-10
4
BROWN
5 VOLT RETURN
5 VOLT RETURN
5 VOLT RETURN
Shielded Twisted
Cable Pair
1
2
J2-04
J2-13
23X
FLYWHEEL
CKP
Sensor
BLACK/WHITE
GREEN/WHITE
CKP HIGH
CKP LOW
Flywheel Teeth Make Up
Target Wheel
FUSE/RELAY BLOCK
IGN Switch
VIOLET
