Section 3: Wire Schematics and Pin-Outs 87
Models 490000/540000/610000 Fuse/Relay Block
20A Fuse
Battery
(Yellow)
Main Power
Relay
15A Fuse
Ignition
(Blue)
Fuel Pump
Relay
(Models 540000/610000 Only)
6
5
4
3
2
1
12
11
10
98
7
