Briggs & Stratton VANGUARD 810 EFI User Manual

Section 3: Wire Schematics and Pin-Outs 79
Model 490000 Engine to Chassis 8-Place Connector Pin-Out
(Optional)
Engine Connector
5
5
6
6
7
7
8
8
1
1
2
2
3
3
4
4
VIOLET
VIOLET
IGN
MIL
MIL
Safety
Interrupt
Starter
J2 15
J1 03J1 14
O
1.4W Lamp or
LED with Resister
Starter
Ignition
Switch
ECM
ORANGE/WHITE
ORANGE/WHITE
ORANGE/BLACK
ORANGE/BLACK
YELLOW/RED
YELLOW/RED
+12V
Safety Circuit Input
15A Fuse
Ignition
(Blue)
Oil Pressure Switch
GREEN
Chassis Connector (Equipment Side)
