Receiving a fax
27
4
Receiving faxes into memory
(MFC-7360N and
MFC-7460DN) 4
As soon as the paper tray becomes empty
during fax reception, the screen will display
No Paper. Put some paper in the paper tray.
(See Loading paper and print media in
Chapter 2 of the Basic User’s Guide.) If you
are unable to put paper in the paper tray the
following will happen:
If Memory Receive is On: 4
The machine will carry on receiving the fax,
with the remaining pages being stored in
memory, if enough memory is available.
Further incoming faxes will also be stored into
memory until the memory is full. When the
memory is full the machine will stop
automatically answering calls. To print the
faxes, put fresh paper in the tray and press
Start.
If Memory Receive is Off: 4
The machine will carry on receiving the fax,
with the remaining pages being stored in
memory, if enough memory is available. The
machine will then stop automatically
answering calls until fresh paper is put in the
paper tray. To print the last fax you received,
put fresh paper in the tray.
a Make sure you are in Fax mode .
b Press Menu, 2, 1, 6.
c Use a or b to choose On or Off.
Press OK.
d Press Stop/Exit.
Setting the Print Density 4
You can adjust the Print Density setting to
make your printed pages darker or lighter.
a Make sure you are in Fax mode .
b For MFC-7360N and MFC-7460DN,
press Menu, 2, 1, 7.
For MFC-7860DW, press Menu, 2, 1, 6.
c Press c to make the print darker.
Or, press d to make the print lighter.
Press OK.
d Press Stop/Exit.
Printing a fax from the
memory 4
If you are using the Fax Storage feature
(Menu, 2, 5, 1), you can still print a fax from
the memory when you are at your machine.
(See Fax Storage on page 20.)
a Press Menu, 2, 5, 3.
b Press Start.
c Press Stop/Exit.
