Chapter 5
32
BT Call Sign (U.K. only) 5
The BT Call Sign subscriber service is a way
to have a separate number for your machine,
it allows you to have at least two separate
telephone numbers on one phone line. Each
phone number has its own distinctive ringing
pattern.
You can set up your machine so that it only
responds to the second number.
When you set the BT Call Sign feature to ON,
the receive mode is set to Manual
automatically. Manual mode will not respond
to incoming telephone calls, since the
number you use for telephone calls will use
the normal ring pattern. If you turn the feature
off, your receive mode will remain on
Manual.
To enable the machine to work with BT
Call Sign
5
This feature will only work with your external
phone.
a Press Menu, 2, 0, 2.
The screen displays the current setting.
b Press a or b to choose On or Off.
Press OK.
c Press Stop/Exit.
Additional dialling
operations 5
Combining quick dial
numbers 5
You can combine more than one Quick Dial
number when you dial. This feature may be
useful if you need to dial an access code for
a cheaper rate from another long distance
carrier.
For example, you might have stored ‘555’ on
Speed Dial #003 and ‘7000’ on Speed Dial
#002. You can use them both to dial
‘555-7000’ if you press the following keys:
Press (Address Book) 003.
Press (Address Book) 002 and Start.
Numbers can be added manually by entering
them on the dial pad:
Press (Address Book) 003, 7001 (on the
dial pad), and Start.
This would dial ‘555–7001’. You can also add
a pause by pressing Redial/Pause key.

Table of Contents

Other manuals for Brother HL-2130

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-2130 and is the answer not in the manual?

Brother HL-2130 Specifications

General IconGeneral
Network readyNo
N-up printing2, 4, 16, 25
Print technologyLaser
Maximum resolution2400 x 600 DPI
Time to first page (black, normal)10 s
Print speed (black, normal quality, A4/US Letter)20 ppm
Maximum duty cycle- pages per month
Number of print cartridges1
Maximum internal memory- MB
Sound power level (standby)31 dB
Sound pressure level (printing)53 dB
DisplayLED
Total input capacity250 sheets
Total output capacity100 sheets
Custom media width69.9 - 215.9 mm
Maximum print size216 x 406 mm
Custom media length116 - 406.4 mm
Paper tray media typesBond paper, Plain paper, Recycled paper
Paper tray media weight60 - 105 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Standard interfacesUSB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)62 W
Power consumption (printing)421 W
Power consumption (PowerSave)0.8 W
Package weight8000 g
Power LEDYes
Sustainability certificatesENERGY STAR
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)368 x 360 x 183 mm
