APPENDIX
191
5
*1
Do not create folders in “Removable Disk” on a computer.
If embroidery data is stored in a folder in “Removable Disk”, that embroidery data cannot be retrieved by the machine.
*2
The wireless network connection complies with IEEE 802.11 n/g/b standards and uses the 2.4 GHz frequency.
A wireless network cannot be set up with WPA/WPA2 Enterprise.
*3
Using data other than that saved using our data design systems or this machine may cause this machine to malfunction.
When the machine is used to save a file with any extension, it is saved as a .phx data file.
.dst data is displayed in the pattern list screen by file name (the actual image cannot be displayed).
The full file name may not be displayed depending on the number of characters in the file name.
Since Tajima (.dst) data does not contain specific thread color information, it is displayed with our default thread color sequence.
Check the preview and change the thread colors as desired.
*4
USB media is commercially available, but some USB media may not be usable with this machine.
Please visit our website “ http://s.brother/cpbag/
” for more details.
* Depending on the type of USB devices/media being used, either directly plug the USB device into the machine’s USB port or plug the
USB media Reader/Writer into the machine’s USB port.
* Please be aware that some specifications may change without notice.
Condition of the [Eco
Mode] and [Shutoff
Support Mode]
[Eco Mode] Available time [OFF], 10 - 120 (minute)
“Start/Stop” button Green flashing
Suspended function Machine light, Screen display
After recovering The machine starts from the previous operation.
[Shutoff Support Mode] Available time [OFF], 1 - 12 (hour)
“Start/Stop” button Green slow flashing
Suspended function All functions
After recovering An error message appears.
You need to turn off and on the machine to restart.
Compatible image files of
the Screen Saver Image
Format JPEG format (.jpg)
File size Max. 2 MB for each image
File dimension 1280 (H) × 1200 (W) pixels or less (If the size is more
than 1280 (H) × 800 (W) pixels, the image will be
displayed in a smaller size.)
Number allowed 5 or less
Videos that can be
played
MP4 file format Video - H.264/MPEG-4 AVC, Audio – AAC
Size 1280 (H) × 800 (W) pixels or less (If the size is more
than 450 (H) × 800 (W) pixels, the video will be
displayed in a smaller size.)
Maximum file size 100 MB
Item Specification
• When using embroidery data other than our original patterns, the thread or needle may break when
embroidering with a stitch density that is too fine or when embroidering three or more overlapping
stitches. In that case, use one of our original data design systems to edit the embroidery data.
To Next Page
