Canon imagePRESS C6010 User Manual

Version 2 imagePRESS C6010 Customer Expectations Document Page 10
3. Machine Dimensions and Space Requirements
3.1 Dimensions
The following table includes the width, height, and depth dimensions (in inches and
millimeters) of the main unit and optional accessories.
Unit
Width
Depth
Height
Main Unit
*1
101.8”
2,586 mm
45.4”
1,152 mm
52.4”
1,330 mm
POD Deck-A1
38.7”
982 mm
31.2”
792 mm
43.1”
1,095 mm
POD Deck-A1 &
Secondary PODDeck-A1
70.6” 1,793 mm 31.2" 792 mm 43.1” 1,095 mm
Paper Deck-AC1
23.7”
601 mm
24.4”
621 mm
22.4”
570 mm
Stack Bypass-A1
*5
15.7”
398 mm
21.4”
544 mm
13.4”
339 mm
Color Image Reader-H1
28.8”
732 mm
23.4”
595 mm
4.1”
105 mm
DADF-R1
25.4”
646 mm
22.4”
570 mm
5.6”
143 mm
Professional Puncher-B1
& Professional Puncher
Integration Unit-A1
22.0” 560 mm 31.2” 792 mm 40.9” 1,040 mm
High Capacity
Stacker-C1
33.9” 860 mm 30.1” 765 mm 48.8” 1,240 mm
High Capacity
Stacker-F1
35.4” 899 mm 29.3” 745 mm 40.9”
*7
1,040 mm
*7
Saddle Finisher-AJ2
*3
41.7”
1,060 mm
31.2”
792 mm
46.5”
1,180 mm
Finisher-AJ1
*2
35.0”
890 mm
31.2”
792 mm
46.5”
1,180 mm
Puncher Unit-BB1
Part of the Finisher-AJ1 or Saddle Finisher-AJ2
Booklet Trimmer-D1
*2
&
Saddle Finisher-AJ2
*3
74.4” 1,890 mm 31.2” 792 mm 46.5” 1,180 mm
Booklet Trimmer-D1,
Two-Knife Booklet
Trimmer-A1, & Saddle
Finisher-AJ2
95.7” 2,431 mm 31.2” 792 mm 46.5” 1,180 mm
Document Insertion
Unit-C1
24.6” 625 mm 26.3” 667 mm 8.4” 213 mm
Perfect Binder-B1
*4
36.3”
922 mm
31.1”
791 mm
53.5”
1,360 mm
Square Fold
Booklet-Maker &
Two-Knife Trimmer
*6
62.3” 1,582 mm 51.1” 1,298 mm 51.0” 1,295 mm
*1 The Marking Engine, Sub Station, and Power Station Unit all make up what is hereinafter
referred to as the “Main Unit.”
*2 The expansion tray is attached.
*3 The auxiliary booklet tray is attached.
*4 The Insertion Unit is included.
*5 The auxiliary tray is extended.
*6 The Square Fold Booklet-Maker Conveyor Tray is fully extended.
*7 When the eject tray is extended the depth is 49.2” (1,250 mm).
