3.3.1 Minimum Space Requirements to Transport the Machine and Turn Hallway
Corners
The following table represents the minimum width that is necessary to turn
hallway corners and transport the machine to its final installation site.
Equipment
Dimensions When Transporting
(Depth x Width)
Minimum Corridor Width
Required
Marking Engine
54 3/4” x 43 1/2”
(1,390 mm x 1,105 mm)
89 5/8”
(2,276 mm)
Sub Station
47 1/4” x 31 1/8”
(1,200 mm x 792 mm)
76 1/4”
(1,938 mm)
Power Station Unit
54 1/2” x 8 1/8”
(1,383 mm x 227 mm)
74 7/8”
(1,902 mm)
POD Deck-A1
38 5/8” x 31 1/4”
(982 mm x 792 mm)
69 3/8”
(1,762 mm)
Secondary POD Deck-A1
31 1/4” x 29 3/8”
(792 mm x 745 mm)
62 1/2”
(1,587 mm)
Professional Puncher-B1
31 1/4” x 12”
(792 mm x 305 mm)
53 1/8”
(1,349 mm)
Professional Puncher
Integration Unit-A1
31 1/4” x 9 7/8”
(792 mm x 250 mm)
52 3/8”
(1,331 mm)
High Capacity Stacker-C1
33 7/8” x 30 1/8”
(860 mm x 765 mm)
65”
(1,651 mm)
Perfect Binder-B1
36 5/16” x 31 1/8”
(922 mm x 791 mm)
67 1/2”
(1,715 mm)
Saddle Finisher-AJ2
31 1/2” x 31 1/4”
(800 mm x 792 mm)
64”
(1,626 mm)
Finisher-AJ1
31 1/2” x 31 1/4”
(800 mm x 792 mm)
64”
(1,626 mm)
Booklet Trimmer-D1
62” x 30 3/8”
(1,575 mm x 770 mm)
88 3/4”
(2,254 mm)
Two-Knife Booklet
Trimmer-A1
30 3/8” x 21 1/8”
(770 mm x 536 mm)
56 5/8”
(1,439 mm)
Document Insertion
Unit-C1
26 1/4” x 24 5/8”
(667 mm x 625 mm)
55 5/8”
(1,414 mm)
NOTE
The Marking Engine, Sub Station, and Power Station Unit are transported
separately.
