Canon LX-MU800Z User Manual

100
Supported Signal Input Timing
Computer
Signal
Type
Resolution Freq. H
(KHz)
Freq. V
(Hz)
Clock
(MHz)
BNC -
RGBHV
BNC -
YUV
HD15 -
RGBHV
HD15-
YUV
DVI-D
(EIA Timing)
HDMI
RGB
(EIA Timing)
HDMI
YUV
(EIA Timing)
HDBaseT
PC 640*480-60 31.47 59.93 25.175 V - V - V V - V
640*480-75 37.5 75 31.5 V - V - V V - V
640*480-85 43.27 85.01 36 V - V - V V - V
800*600-60 37.88 60.32 40 V - V - V V - V
800*600-75 46.88 75 49.5 V - V - V V - V
800*600-85 53.67 85.06 56.25 V - V - V V - V
848*480-60 31.02 60 33.75 V - V - V V - V
1024*768-60 48.36 60 65 V - V - V V - V
1024*768-75 60.02 75.03 78.75 V - V - V V - V
1024-768-85 68.88 85.03 94.5 V - V - V V - V
1280*720-60 44.69 59.91 74.37 V - V - V V - V
1280*768-60 47.8 59.87 79.5 V - V - V V - V
1280*800-60 49.702 59.81 83.5 V - V - V V - V
1280*960-60 60 60 108 V - V - V V - V
1280*1024-60 63.98 60.02 108 V - V - V V - V
1280*1024-75 79.98 75.02 135 V - V - V V - V
1280*1024-85 91.15 85.02 157.5 V - V - V V - V
1366*768-60 47.71 59.79 85.5 V V V V V
1440*900-60 55.935 59.887 106.5 V - V - V V - V
1400X1050-60 65.517 59.98 121.75 V - V - V V - V
1600*1200-60 75 60 162 V - V - V V - V
1680*1050-59.94 65.179 59.94 146 V - V - V V - V
1920*1200RB-60 74.04 59.95 154 V - V - V V - V
SDTV 1440x480i 15.73 60 27 - - - - - V V V (HDMI)
1440x576i 15.62 50 27 - - - - - V V V (HDMI)
480i 15.734 59.94 13.5 - V - V - - - -
576i 15.625 50 13.5 - V - V - - - -
EDTV 480p 31.47 59.94 27 V V V V V V V V
576p 31.25 50 27 V V V V V V V V
1080i 28.13 50 74.25 - V - V V V V V
1080i 33.75 60 74.25 - V - V V V V V
720p 37.5 50 74.25 V V V V V V V V
720p 45 60 74.25 V V V V V V V V
1080p 27 24 74.25 V V V V V V V V
1080p 28.13 25 74.25 V V V V V V V V
1080p 33.72 29.97 74.175 V V V V V V V V
1080p 33.75 30 74.25 V V V V V V V V
1080p 56.25 50 148.5 V V V V V V V V
1080p 67.5 60 148.5 V V V V V V V V
3D Signal Input Mode
Timing
Format
H Freq. V Freq. Pixel H H H H H V V V V V Note
(KHz) (Hz) Clock
(MHz)
Total
Pixel
Display
Pixel
Front
Porch
Sync Back
Porch
Total
Lines
Display
Lines
Front
Porch
Sync Back
Porch
Auto
720p_50 37.5 50 74.25 1980 1280 440 40 220 750 720 5 5 20 OK
720p_60 45 60 74.25 1650 1280 110 40 220 750 720 5 5 20 OK
1080i_50 28.125 25 74.25 2640 1920 528 44 148 562 540 2 5 15 OK
1080i_60 33.75 30 74.25 2200 1920 88 44 148 562 540 2 5 15 OK
1080p_24 27 24 74.25 2750 1920 638 44 148 1125 1080 4 5 36 OK
1080p_50 56.25 50 148.5 2640 1920 528 44 148 1125 1080 4 5 36 OK
1080p_60 67.5 60 148.5 2200 1920 88 44 148 1125 1080 4 5 36 OK
* The following Timing Formats require 3D formats carrying InfoFrame packets (based on the HDMI 1.4a standard) from
HDMI or HDBaseT sources only.
Timing Format
3D Format Support
FP SBS TAB
720p_50
V V V
720p_60
V V V
1080i_50
V
1080i_60
V
1080p_24
V V V
1080p_50
V V
1080p_60
V V
