Canon XH A1S User Manual

119
Using a Memory Card
Using an Optional Flash
You can use E-TTL II-compatible Canon Speedlite flashes designed for use with Canon SLR cameras,
including the 420EX/430EX/430EX II/550EX/580EX/580EX II models, to record natural still images under
low light conditions. Refer also to the instruction manual of the Speedlite flash.
The following procedures are explained using a Canon 580EX II Speedlite Flash.
Connecting a Speedlite Flash
When connecting a Canon Speedlite flash you cannot use the Off-Camera Shoe Cord designed for Canon
EOS SLR cameras.
Always turn off the camcorder when connecting or removing the flash.
1. Slip the flash’s mounting foot all the way into the camcorder’s hot shoe.
2. Slide the lock lever on the mounting foot to the right until it clicks in place.
To remove the flash:
Press and hold the lock-release button and slide the lock lever to the left and then remove the flash form the
hot shoe.
Using the Flash
1. Set the dial to a recording mode other than M and turn on the flash.
• While the Speedlite flash is charging, the indicator will flash in white. Once charged, the indicator
will stay on in green.
• If the indicator keeps flashing in white for a long time, replace the flash’s batteries.
2. Press the PHOTO button to record a still image.
 Wait until the flash is charged before recording the still image. You can record a still image while
the flash is charging, but the flash will not go off.
 Turn off the Speedlite flash when you are not using it.
 The flash will not go off during exposure lock and in the M Manual mode.
 While using the flash, the shutter speeds that can be set in Tv mode are 1/4 – 1/500.
 The camcorder does not support the Bounce Flash function or the Wireless Multiple Flash System
function of the Speedlite 420EX/430EX/430EX II/550EX/580EX/580EX II flashes.
 The camcorder does not support the ST-E2 Wireless Speedlite Flash Transmitter or the Wireless
Master/Slave Control function of the Speedlite 420EX/430EX/430EX II/550EX/580EX/580EX II
flashes.
 When recording under very dark conditions, as you keep the PHOTO button pressed halfway, the
AF assist lamp of the Speedlite flash may light up (only when recording using autofocus and with
[CAMERA SETUP] [FOCUS PRI.] set to [ON]).
 The Speedlite flash will not go off when the drive mode is set to Auto Exposure Bracketing.

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
