Extern al Connections
Video Signal Output Standards
The standard of the video signal output from the HD/SD SDI ( only), HD/SD COMPONENT OUT
and HDV/DV terminals depends on the standard used for recording (or the standard of the recording on
the tape being played back) and on various menu settings. Video output from the VIEWFINDER
COMPONENT OUT, A/V1, or VIDEO 2 terminal will always be in 480/60i standard.
Standard of Video Output while Recording
While recording in high definition, video output from the HD/SD SDI terminal will be an
uncompressed HD, YPbPr signal. You can down-convert the video output with the respective menu settings.
Standard of Video Output during Playback
When playing back a tape recorded in HDV standard, video output from the HD/SD SDI terminal will
be a signal modified from the HDV video. You can down-convert the video output with the respective menu
settings.
1
only.
2
[SIGNAL SETUP] [SDI SPEC.] set to [SD LOCKED].
3
[SIGNAL SETUP] [COMP.OUT] set to [480i].
4
[SIGNAL SETUP] [HD DOWN-CONV] set to [ON].
5
16:9 picture is horizontally squeezed to a 4:3 aspect ratio.
6
On-screen displays will not be embedded in the video output even if [SIGNAL SETUP] [SDI OUTPUT] is set to
[ON(OSD)].
7
On-screen displays will not be embedded in the video output even if [DISPLAY SETUP/ ] [TV SCREEN] is set to
[ON].
8
Converted to 60i.
9
Converted to 60i using the 2:3 pulldown method.
10
When a time code signal is output from the TIME CODE or HD/SD SDI terminal, the user bit for this signal can be set to
2:3 pulldown data ( 42).
11
Converted to 60i using the method selected in [CAMERA SETUP] [24F MODE SEL].
Recording standard
and frame rate
HD/SD SDI terminal
1
HD/SD COMPONENT OUT terminal
HDV/DV terminal
Unchanged
Down-
converted
2, 5, 6
Unchanged
Down-
converted
3, 5
HD 60i 1080/60i 480/60i 1080/60i 480/60i 1080/60i
HD 30F 1080/60i 480/60i
8
1080/60i 480/60i
8
1080/30p
HD 24F 1080/60i 480/60i
9,10
1080/60i 480/60i
9
1080/24p
SD (60i, 30F
8
, 24F
11
) 480/60i 480/60i 480/60i
Standard of
the tape
[LETTERBOX]
setting
HD/SD SDI terminal
1
HD/SD COMPONENT OUT terminal HDV/DV terminal
Unchanged
Down-
converted
2, 5
Unchanged
Down-
Converted
3, 5
Unchanged
Down-
Converted
4, 7
HDV
1080/60i
[OFF] 1080/60i 480/60i 1080/60i 480/60i
1080/60i 480/60i
[ON] 480/60i 480/60i
HDV
1080/30p
[OFF] 1080/60i
8
480/60i 1080/60i
8
480/60i
1080/30p 480/60i
[ON] 480/60i
8
480/60i
8
HDV
1080/24p
[OFF] 1080/60i
9,10
480/60i 1080/60i
9
480/60i
1080/30p 480/60i
[ON] 480/60i
9
480/60i
9
DV
480/60i
[OFF]/[ON] 480/60i 480/60i 480/60i
