64
Gain Fine Tuning
1. Set the dial to M, , Tv or Av.
2. Open the menu and select [CAMERA SETUP]. Select the [GAIN SETTING] submenu
and then one of the GAIN switch options.
3. Select [TUNE 0.0dB] and press the SELECT/SET dial.
4. Turn the SELECT/SET dial to select the desired gain level and press the dial.
After the setting, you will return to the [GAIN SETTING] submenu. Assign the gain values to the other
GAIN switch options in the same way.
5. Close the menu.
Selecting the Gain Level
1. Set the dial to M, , Tv or Av.
2. Set the AGC switch to OFF.
3. Set the GAIN switch to the desired gain
position.
When you select high gain levels, the picture may flicker slightly. The 36.0 dB gain level in
particular, allows you to shoot video with a higher sensitivity but is more prone to the appearance
of noise and artifacts (white dots, vertical streaks or blocking).
When the AGC switch is set to ON you can activate the gain limit to prevent the camcorder from
setting a level higher than a preset limit between 3 dB and 15 dB.
Open the menu and select [CAMERA SETUP]. Select [AGC LIMIT], set the maximum gain level
and close the menu.
MENU
(27)
CAMERA SETUP GAIN SETTING GAIN L•••±0dB TUNE•••0.0dB
GAIN M•••6dB
GAIN H•••12dB
AGC switch
GAIN switch
