Canon XH A1S User Manual

19
Preparations
Preparing the Camcorder
Attaching and Detaching the Eye Cup
Attaching the Eye Cup
Attach the eye cup so that it covers the rubber portion of viewfinder unit.
• The dioptric adjustment lever can be operated even with the eye cup attached.
• For left eye use, attach the eye cup so that the protruding portion faces the opposite side.
Detaching the Eye Cup
Detach the eye cup as shown in the
illustration.
Dioptric Adjustment
Turn on the camcorder and adjust the
dioptric adjustment lever.
Do not let the viewfinder be exposed to direct sunlight or other strong light sources. The viewfinder
LCD may become damaged due to concentration of the light by the lens. Pay special attention when
mounting the camcorder on a tripod, or during its transportation.
Viewfinder
unit

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
