Canon XH A1S User Manual

130
[MARKERS]: You can display the on-screen markers to help you accurately frame your subject. Select from
a center marker, a horizontal level marker or a grid. You can also adjust the intensity of the markers display
(102).
[ASPECT GUIDE]: Use the aspect ratio guides as a reference to accurately frame subjects. You can select to
display the aspect guides for 4:3, 13:9, 14:9, 1.66:1, 1.75:1, 1.85:1 or 2.35:1 (Cinemascope).
[SAFETY ZONE]: The safety zone guide shows a frame including 80% or 90% of the screen area. Use it as
a reference to accurately frame subjects.
1
only.
 SYSTEM SETUP/
Menu item (Submenu item and) Setting options
CUSTOM KEY 1 TIME CODE, INDEX WRITE, ZEBRA, VCR STOP, TV
SCREEN, TC HOLD, AUDIO LEVEL, CVF+LCD BW,
MAGN.B.LOCK, SHTR D.LOCK, E.LCK B.LCK, SDI
OUTPUT
1
, FOCUS LIMIT, IMAGE STAB, OUTPUT CH,
(NONE)
– – – 73
TIME CODE, TV SCREEN, DATA CODE, AUDIO
LEVEL, TC HOLD, CVF+LCD BW, SDI OUTPUT
1
,
OUTPUT CH, (NONE)
– – – 73
ZEBRA, TV SCREEN, CVF+LCD BW,
MAGN.B.LOCK, SHTR D.LOCK, E.LCK B.LCK, SDI
OUTPUT
1
, FOCUS LIMIT, IMAGE STAB, OUTPUT CH,
(NONE)
– – – 73
TV SCREEN, CVF+LCD BW, SDI OUTPUT
1
, (NONE) – – – 73
CUSTOM KEY 2 TIME CODE, INDEX WRITE, ZEBRA, VCR STOP, TV
SCREEN, TC HOLD, AUDIO LEVEL, CVF+LCD BW,
MAGN.B.LOCK, SHTR D.LOCK, E.LCK B.LCK, CP
BKWD KEY, SDI OUTPUT
1
, FOCUS LIMIT, IMAGE
STAB, OUTPUT CH, (NONE)
– – – 73
TIME CODE, TV SCREEN, DATA CODE, AUDIO
LEVEL, TC HOLD, CVF+LCD BW, SDI OUTPUT
1
,
OUTPUT CH, (NONE)
– – – 73
ZEBRA, TV SCREEN, CVF+LCD BW,
MAGN.B.LOCK, SHTR D.LOCK, E.LCK B.LCK, CP
BKWD KEY, SDI OUTPUT
1
, FOCUS LIMIT, IMAGE
STAB, OUTPUT CH, (NONE)
– – – 73
TV SCREEN, CVF+LCD BW, SDI OUTPUT
1
, (NONE) – – – 73
WL.REMOTE 1, 2, OFF 111
POWER SAVE ON, OFF – – 31

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
