128
1
Available only when recording in standard definition (SD).
2
only.
[DV REC MODE]: When recording in standard definition (SD mode) only, you can choose between SP
(standard play) and LP (long play). LP extends the tape usage by 1.5 times.
Depending on the tape and its usage condition, picture and sound recorded in LP mode may be
distorted. We recommend using SP mode for important recordings.
If you record in both SP and LP modes on the same tape, the playback picture may become
distorted, and the time code may not be written correctly.
If you play back on this camcorder, a tape that was recorded in LP mode with another digital device
or vice versa, the picture and sound may become distorted.
1
Available only when recording in standard definition (SD).
[OUTPUT LEVEL]: Select the amplitude of the audio output signal.
RECORDING SETUP
Menu item Setting options
DV REC MODE SP, LP
1
– – 104
UB REC
2
INT.USR-BIT, EXT.USR-BIT – – – 48
UB SELECT 00 00 00 00, TIME, DATE – – 48
IMG QUALITY SUPER FINE, FINE, NORMAL – 112
IMAGE SIZE [SIGNAL STD.] is set to [HD] or [SD16:9]:
LW 1920x1080, SW 848X480
[SIGNAL STD.] is set to [SD4:3]:
L 1440x1080, S 640X480
– – – 112
LW 1920x1080, SW 848X480,
L 1440x1080, S 640X480
– – –
HD IMG SIZE LW 1920x1080, SW 848X480 – – – 115
FILE NOS. RESET, CONTINUOUS – 113
AUDIO SETUP
Menu item Setting options
AUD.M.SET CH , CH , MIX/FIXED, MIX/VAR. – – – 52
MIX BALANCE – – – 83
DV AUDIO 16bit, 12bit
1
– – 49
MONITOR SEL. NORMAL, LINE OUT – – – 83
OUTPUT LEVEL 1Vrms, 2Vrms – 83
OUTPUT CH CH /CH , CH /CH , CH /CH ,
ALL CH/ALL CH
– – 83
CH /CH , CH /CH ,
CH /CH , ALL CH/ALL CH
– – –
CH1 INPUT INT/EXT MIC, XLR MIC, XLR LINE – – 50
CH2 INPUT – – 50
XLR REC CH CH1, CH1/CH2 – – 51
LOW CUT OFF, LC1, LC2 – – 49
MIC SENSIT. NORMAL, HIGH – – 49
XLR 1 TRIM +12dB, +6dB, 0dB, -6dB, -12dB – – 51
XLR 2 TRIM
XLR ALC LINK LINK, SEP – – 51
AUD.LIMITER ON, OFF – – 51
1/2 3/4
1/2 3/4
