Canon XH A1S User Manual

67
Recording
Zebra Pattern
This camcorder has a zebra pattern feature that shows black and white diagonal stripes over the areas
that are overexposed. The zebra pattern is only displayed on the screen and will not affect your
recordings. The zebra pattern will not be displayed while the Peaking function is activated ( 39).
Available zebra pattern settings: 70 IRE, 75 IRE, 80 IRE, 85 IRE, 90 IRE, 95 IRE, and 100 IRE.
Selecting the Zebra Pattern Level
Open the menu and select [DISPLAY SETUP/ ]. Select [ZEBRA LEVEL], select a setting
option and close the menu.
Activating the Zebra Pattern
Open the menu and select [DISPLAY SETUP/ ]. Select [ZEBRA], set it to [ON] and close
the menu.
MENU
(27)
DISPLAY SETUP/ ZEBRA LEVEL •• 85
MENU
(27)
DISPLAY SETUP/ ZEBRA •••••••• OFF

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
