Canon XH A1S User Manual

50
Recording Audio
Select the audio input from the built-in microphone or external microphone (MIC terminal), XLR MIC
(XLR terminals) or XLR LINE (XLR terminals). You can select the audio input independently for channel 1
and channel 2.
Selecting the Audio Channel
Open the menu and select [AUDIO SETUP]. Select [CH1 INPUT] or [CH2 INPUT], select a
setting option and close the menu.
Using an External Microphone
When you connect an external microphone to the MIC terminal, the built-in microphone will
automatically be turned off. If necessary, you can use the microphone holder.
External Microphones that can be Connected
Microphone Type: Condenser microphones with independent power supply.
Type of Plug: ∅ 3.5 mm
Input Impedance: 600 ohms
Sensitivity: -66 dBV (manual volume center)
Maximum microphone diameter: ∅ 25 mm
Use commercially available microphones.
MENU
(27)
AUDIO SETUP CH1 INPUT•••INT/EXT MIC
CH2 INPUT•••INT/EXT MIC
CH1 input terminal
CH2 input terminal
MIC (external microphone) terminal

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
