Canon XH A1S User Manual

71
Recording
Selective Noise Reduction
With the selective noise reduction function you can set the camcorder to detect the characteristics of a
certain color or tone and automatically reduce noise in the targeted areas. This is particularly useful for
chroma keying, as targeting the selective noise reduction to the color of the background green or blue
screen will result in a smoother composite picture.
Targeted areas will be identified on the screen by a zebra pattern alternating with the normal picture. On
a connected monitor or computer, targeted areas will be identified by white areas alternating with the
normal picture.
Determining the Area to be Corrected
1. Open the menu, select [CAMERA SETUP] and then select the [SELECTIVE NR]
submenu.
2. Select each setting option, adjust the levels as necessary and close the menu.
• [HUE]: Select the base hue (-6 to 6) of the color to be detected. Use the following values as an
approximate reference: -6=blue-violet, 0=cyan, 6=yellowish green.
• [CHROMA]: Adjust the color saturation for the color to be detected. 13 levels (-6 to 6) are available; set
higher levels to detect areas with richer colors.
• [AREA]: Adjust the color range for the color to be detected. 13 levels (-6 to 6) are available; set
higher levels to detect a wider color range.
• [Y LEVEL]: Adjust the brightness for the color to be detected. 13 levels (-6 to 6) are available; set
higher levels to detect brighter areas.
Activating the Selective Noise Reduction
1. Open the menu and select [CAMERA SETUP]. Select the [SELECTIVE NR] submenu
and then select [EFFECT LEVEL].
2. Select a setting option and close the menu.
• You can select the strength of the effect from low, middle or high.
• appears.
MENU
(27)
CAMERA SETUP SELECTIVE NR HUE •••••••••••••• 0
CHROMA
••••••••••• 0
AREA
••••••••••••• 0
Y LEVEL
•••••••••• 0
MENU
(27)
CAMERA SETUP SELECTIVE NR EFFECT LEVEL •• OFF

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
