83
External Connections
Audio Output
Selecting the Audio Channel
You can select the channel for audio signal output from the A/V1 terminal.
* Default value in mode.
Open the menu and select [AUDIO SETUP]. Select [OUTPUT CH], select a setting option
and close the menu.
While recording external video with 4-channel audio from the HDV/DV terminal, the available options will be
[CH /CH ], [CH /CH ], [CH /CH ], and [ALL CH/ALL CH]. During playback, the audio output differs
according to the setting option and audio input.
1
Playback of a tape recorded with 4-channel audio (using another device)
Selecting the Audio Output Level
You can boost the level of the audio output signal from the A/V1 terminal from 1 Vrms to 2 Vrms (+6 dB).
Open the menu and select [AUDIO SETUP]. Select [OUTPUT LEVEL], select a setting
option and close the menu.
The output level from the headphone terminal does not change.
Selecting the Audio Monitor
Open the menu and select [AUDIO SETUP]. Select [AUD.M.SET], select a setting option
and close the menu.
• You can also select the audio monitor using the wireless controller.
• If you selected [MIX/VAR.], adjust the mix balance with the [MIX BALANCE] setting or using the MIX
BALANCE buttons on the wireless controller.
MENU
(27)
AUDIO SETUP OUTPUT CH•••CH /CH *
Setting Option → [CH /CH ] [CH /CH ] [CH /CH ] [ALL CH/ALL CH]
Audio Input ↓
HDV/DV input 2 channels CH1/CH2 CH1/CH1 CH2/CH2 ALL CH/ALL CH
4 channels
1
Operates according to the [AUD.M.SET] setting ( 83).
Analog input CH1/CH2 CH1/CH1 CH2/CH2 ALL CH/ALL CH
MENU
(27)
AUDIO SETUP OUTPUT LEVEL•••1Vrms
MENU
(27)
AUDIO SETUP AUD.M.SET ••• CH

Canon XH A1S Specifications

General

Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.5 - 90 mm
Focal length (35mm film equivalent)	32.5 - 650 mm
Sensor type	CCD
Total megapixels	1.67 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	1.56 MP
Display diagonal	2.8 \
Display resolution (numeric)	207000 pixels
Maximum image resolution	1920 x 1080 pixels
Still image resolution(s)	1920 x 1080
3D	No
Camcorder type	Shoulder camcorder
Minimum illumination	0.3 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Camcorder tape type	HDV
Camcorder media type	Memory card, Videotape
Compatible memory cards	MMC, SD, SDHC
Internal storage capacity	0 GB
Product color	Black
Built-in flash	-
Battery capacity	- mAh

Weight and Dimensions

Depth	394 mm
Width	163 mm
Height	192 mm
Weight	2135 g
