5-"PRINTER"APPLICATION
Connecttoaprinter
Thedisplayiscapableofprintingscreencontentstoa
portable,thermaldotmatrixprinterthatusespaperrolls.
Printersthataredesignedtobepoweredbythevehicle
batteryorbyaportablebatterypacksimplifyinstallation
andareideal.
NOTE:TheA630,A631,andA632seriesprintersfrom
Axiohmareshownintheseexamples.Visitwww.ax-
iohm.bizformoreinformation.
RCPH11DSP024BBG1
Largecombinesuseauniqueimplementationforsup-
portingaprinter.TheAxiohmA630printerispowered
andconnectedtotheRS-232portviathediagnosticcon-
nectorontherighthandcontrolmodule(1).Kit84095875
includestheprinter(2),printercable(3),andmount-
inghardware(4)forthisimplementation.Thiskit,with
supportingsoftware,allowsthedisplaytocommunicate
directlywiththeprinterviatheControllerAreaNetwork
(CAN).
RCPH11DSP025BBG2
Othervehiclesrequireadifferentimplementation.An
adapterharnessisrequiredtoconnecttheserial(
RS-232)portontheAFSPro700displaytotheprinter.
TheadapterharnessseparatesportsAandBonthemain
connectiontothedisplay.Fordisplay-readyvehicles(an
existingdisplayharnessconnectorisinthecab),use
adapterharness87732647.Forallothervehicles,use
adapterharness87735690.
Withthisharnessinstalled,Com-A(communicationport
A)istheRS-232portthatisintegratedintothemaincon-
nectorharnessonthebackofthedisplay—the26-pincon-
nector.
RCIL11DSP526BBG3
