Program 2
TE-3000S/4000F/4500F Dealer's Manual
Programming item/clerk descriptors by range
Programming procedure
Program data
Department
up to 16 characters
PLU/flat-PLU
up to 16 characters
PLU 2nd @
up to 16 characters
Contents
Initial character
Department 01
Department 02
Department 03
::
Department 99
DEPT01
DEPT02
DEPT03
:
DEPT99
PLU No.
Contents
Initial character
0001
PLU 0001
0002
PLU 0002
0003
PLU 0003
::
9999
PLU 9999
PLU0001
PLU0002
PLU0003
:
PLU9999
PLU No.
Contents
Initial character
0001
PLU 0001
0002
PLU 0002
0003
PLU 0003
::
9999
PLU 9999
PLU0001
PLU0002
PLU0003
:
PLU9999
6
2
s
6
990000
::
s
6
6
::
6
a
6
::
6
a
6
::
a
6
s
PGM
Mode switch
Starts “0001”.
Department = 05
PLU/flat-PLU = 04
PLU 2nd@ = 54
Ends “the last record”.
Start rec-#
(Max. 4 digits)
End rec-#
(Max. 4 digits)
Program data
(character)
}
~
~
~
124
126
