Chapter 1 SIP and SPA Product Overview
SIP, SSC, and SPA Compatibility
Figure 1-2 Horizontal and Vertical Chassis Slot Orientation for SPAs
•
Each SPA provides a certain number of connectors, or ports, that are the interfaces to one or more
networks. These interfaces can be individually configured using the Cisco IOS command-line
interface (CLI).
• Either a blank filler plate or a functional SPA should reside in every subslot of an SIP during normal
operation to maintain cooling integrity. Blank filler plates are available in single-height form only.
• SPAs support online insertion and removal (OIR). They can be inserted or removed independently
from the SIP. SIPs also support online insertion and removal (OIR) with SPAs inserted in their
subslots.
SIP, SSC, and SPA Compatibility
The following tables show SIP and SPA compatibility by SPA technology area on the Cisco 7600 series
router.
Note For more information about the introduction of support for different SIPs and SPAs, refer to the “Release
History” sections in the overview chapters of the Cisco 7600 Series Router SIP, SSC, and SPA Software
Configuration Guide.
SPA 0 SPA 1
SPA 2 SPA 3
Front of SIP, horizontal chassis slots
SPA 0 SPA 1 SPA 2 SPA 3
Vertical slot orientation
SPA 0 SPA 1
Double-height SPA
SPA 3
SPA 1
Double-height SPA
116887
SPA 0
SPA 2
Table 1-1 SIP and SPA Compatibility Table for ATM SPAs
SPA Product ID SIP Type
Cisco 7600
SIP-200
Cisco 7600
SIP-400
Cisco 7600
SIP-600
Cisco 7600
SSC-400
2-Port and 4-Port OC-3c/STM-1 ATM
SPA
SPA-2XOC3-ATM
SPA-4XOC3-ATM
Yes Yes No No
1-Port OC-12c/STM-4 ATM SPA SPA-1XOC12-ATM No Yes No No
1-Port OC-48c/STM-16 ATM SPA SPA-1XOC48-ATM No Yes No No
