Chapter 3 Overview: Cisco 7600 Series Router Shared Port Adapters
5-Port Gigabit Ethernet SPA Overview
The 5-Port Gigabit Ethernet SPA LEDs are described in Table 3-30.
5-Port Gigabit Ethernet SPA Cables, Connectors, and Pinouts
The interface connectors on the 5-Port Gigabit Ethernet SPA are five individual fiber optic receivers that
support SFPs. Each port can send and receive traffic using the optical fiber connections.
The interface connectors on the 5-Port Gigabit Ethernet SPA are five individual fiber optic receivers that
support SFPs. Each port can send and receive traffic using the optical fiber connections.
SFP Connections
The small form-factor pluggable (SFP) module is an input/output (I/O) device that plugs into the Gigabit
Ethernet optical slots on the 5-Port Gigabit Ethernet SPA, linking the port with a 1000BASE-X
fiber-optic network.
Note The 5-Port Gigabit Ethernet SPA will only accept the SFP modules listed as supported in this document.
An SFP check is run every time an SFP is inserted into the 5-Port Gigabit Ethernet SPA and only SFP
modules that pass this check will be usable by the 5-Port Gigabit Ethernet SPA.
SFP modules exist for technologies other than Gigabit Ethernet and for products other than the 5-Port
Gigabit Ethernet SPA. However, the information in this document pertains only to SFP modules that plug
into the 5-Port Gigabit Ethernet SPA ports.
The SFP module has a receiver port (RX) and a transmitter port (TX) that compose one optical interface.
Table 3-31 and Table 3-32 provide SFP information and specifications.
Table 3-30 5-Port Gigabit Ethernet SPA LEDs
LED Label Color State Meaning
Active/Link Off Off Port is not enabled.
Green On The port is enabled and the link is up.
Amber On The port is enabled and the link is down.
STATUS Off Off SPA power is off.
Amber On SPA power is on and good, and SPA is being configured.
Green On SPA is ready and operational.
Table 3-31 SFP Module Options
SFP Module
Product Number SFP Module Description
SFP-GE-S Short wavelength
(1000BASE-SX)
Contains a Class 1 laser of 850 nm for
1000BASE-SX (short wavelength) applications.
SFP-GE-L Long wavelength/long haul
(1000BASE-LX/LH)
Contains a Class 1 laser of 1310 nm for
1000BASE-LX/LH (long wavelength)
applications.
