Cisco 7600 Series User Manual

3-59
Cisco 7600 Series Router SIP, SSC, and SPA Hardware Installation Guide
OL-5052-08
Chapter 3 Overview: Cisco 7600 Series Router Shared Port Adapters
1-Port Channelized OC-3 STM-1 ATM CEoP SPA Overview
1-Port Channelized OC-3 STM-1 ATM CEoP SPA Overview
The following sections describe the 1-Port Channelized OC-3 STM-1 ATM CEoP SPA:
• 1-Port Channelized OC-3 STM-1 ATM CEoP SPA LEDs
• 1-Port Channelized OC-3 STM-1 ATM CEoP SPA Interface Specifications
• 1-Port Channelized OC-3 STM-1 ATM CEoP SPA Optical Transceiver Modules and Cables
1-Port Channelized OC-3 STM-1 ATM CEoP SPA LEDs
The 1-Port Channelized OC-3 STM-1 ATM CEoP SPA has three types of LEDs. There are two LEDs for
the port on the SPA, and one STATUS LED as shown in the following figure.
Figure 3-41 1-Port Channelized OC-3 STM-1 ATM CEoP SPA Faceplate
Amber On SPA is on and good, and the SPA is being configured.
Green On SPA is ready and operational.
Table 3-38 IPSec VPN SPA LED (continued)
LED Label Color State Meaning
1 C/A (Carrier/Alarm) LED 3 STATUS LED
2 A/L (Active Loopback) LED
230029
3
STATUS
A/L
0
C/A
SPA-1CHOC3-CE-ATM
SPA-1CHOC3-
CE-ATM
CLASS 1 LASER
47-18493-XX REVXX
VID: XXXXXXX
CSA: XXXXXXX
1
2
