Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Overview of Options Configurable from a Phone
4-6
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.1
OL-14620-01
Related Topics
• Displaying a Configuration Menu, page 4-2
• Unlocking and Locking Options, page 4-3
• Editing Values, page 4-4
• Network Configuration Menu, page 4-7
• Device Configuration Menu, page 4-16
Ta b l e 4-1 Settings Configurable from a Cisco Unified IP Phone
Category Description
Network Configuration Menu
Option
DHCP settings Dynamic Host Configuration Protocol (DHCP)
automatically assigns IP address to devices when
you connect them to the network. Cisco
Unified
IP Phones enable DHCP by default.
DHCP Enabled
DHCP Address Released
IP settings If you do not use DHCP in your network, you can
make IP settings manually.
Domain Name
IP Address
Subnet Mask
Default Router 1-5
DNS Server 1-5
TFTP settings If you do not use DHCP to direct the phone to a
TFTP server, you must manually assign a TFTP
server. You can also assign an alternative TFTP
server to use instead of the one assigned by
DHCP.
TFTP Server 1
Alternate TFTP
TFTP Server 2
VLAN settings Admin. VLAN ID allows you to change the
administrative VLAN used by the phone. PC
VLAN allows the phone to interoperate with
third-party switches that do not support a voice
VLAN.
Admin. VLAN ID
PC VLAN
Port settings Allow you to set the speed and duplex of the
network and access ports.
SW Port Configuration
PC Port Configuration
